Inconel 600 Mineral Insulated Heating Cable

Name: Inconel 600 Mineral Insulated Heating Cable
Brand: MICH
Price: 0.5 USD

China Inconel 600 Mineral Insulated Heating Cable factory

Brand Name : MICH

Model Number : IC600SMIHCSC600R

Certification : ISO9001

Place of Origin : China

MOQ : 1 meter

Price : USD0.5-USD5 per meter

Payment Terms : L/C, T/T

Supply Ability : 20 million meters

Delivery Time : in one month

Packaging Details : plywood crates

Sheath : Inconel 600

Conductor : One core

Application : High temperature

Diameter : up to project request

Cable Length : in Meter

Power : in Watt

Vottage : Volt

Unit Weight : Up to 184 kg/km

Contact Now

INCONEL 600 SHEATHED MINERAL INSULATED HEATING CABLE WITH SINGLE CONDUCTOR 600V RATED are special MI heating cable with the sheath material of Inconel 600 and one conductor in the cable with voltage 600 v for harsh environment use, offer excellent oxidation resistance and a strength at very high temperatures (up to 1150 °C). Not recommended for in sulphur atmospheres higher than 550 °C.

Heating Cable Specification (600V Single Core)

Cable Code	Diameter	Nominal resistance at +20℃	Maximum manufacturing length	Unit weight
Cable Code	mm	Ω/m	m	kg/km
16C2.1	6.8	0.0021	130	220.7
16C3.4	5.9	0.0034	173	162.5
16C5.3	5.3	0.0053	214	125.6
16C8.5	4.8	0.0085	261	101.6
16C13	4.3	0.013	325	79.1
16C21	4.0	0.021	376	65.8
16K40	5.8	0.04	179	157.1
16K50	5.4	0.05	206	135.6
16K60	5.2	0.06	222	122.8
16K80	4.8	0.08	261	101.2
16K100	4.7	0.1	200	99.5
16K120	4.5	0.12	200	88.8
16K160	6.5	0.16	200	202.2
16K200	5.9	0.2	200	166.5
16K250	5.3	0.25	215	131.7
16K400	4.7	0.4	280	96.7
16K500	4.5	0.5	300	87.7
16N630	4.3	0.63	185	82.2
16N1000	3.9	1.0	230	62.8
16N1600	3.6	1.6	270	52.4
16N2500	3.4	2.5	300	45.6
16N2800	3.4	2.8	300	45.2
16N3300	3.4	3.3	300	44.7
16N4000	3.2	4.0	350	38.1
16N5200	3.2	5.2	350	37.7
16N6300	3.2	6.3	350	38.4
16N10000	3.2	10	350	38.9

Application

High temperature pipeline heat tracing	Anti-coagulation and viscosity decreasing for process media
Tank/vessel heating	Metal manufacturing industry -- low melting point alloy melting
Extruder shell heating	Recycling of nuclear fuel waste
All kinds of industrial electric heaters

Specification

Heating cable instruction code

MI AL-B 16K6560/60/2520/220/E1

No. 1 2 3 4 5 6 7

No.	Instruction
1	Sheath material	825 alloy
2	structure of cable components	shown in table 1
3	cable codes	shown in table 2, 3 and 4
4	length of heating cable	In meter
5	Heating cable power	In Watt
6	heating cable voltage	In Volt
7	heating cable voltage	See table 5

Cable Code

1 6 K 6560

No. 1 2 3 4

Serial NO.	Instruction
1	core number	1 or 2
2	Voltage grade	3=300V, 6=600V
3	conductor materials	K,N,C
4	cold resistance ×1000	6560=6.56Ω/m×1000

Table 1 Structure of Cable Element

Inconel 600 Mineral Insulated Heating Cable

Cable Structure

Inconel 600 Mineral Insulated Heating Cable

Table 5 terminal specifications

	Model: A, D, E		Model: B
Maximum Voltage(V)	Maximum Current (A)	Terminal Specification	Maximum Current (A)	Terminal Specification
Maximum Voltage(V)	Maximum Current (A)		Maximum Current (A)
600	15	E2	20	E1
600	20	E2	25	E2
600	30	E3	40	E2
600	50	E3	70	E2
600	70	E3	100	E3

Note 1: E1 means 1/2 "NPT;E2 means 3/4 "NPT;E3 represents 1 "NPT (taper thread);Additional connection thread requirements are available.

Note 2: the length of cold end cable with standard configuration is 2 meters. If you increase or decrease of length required, please contact our professional personnel.

Corresponding reference table between the output power and sheath temperature

Inconel 600 Mineral Insulated Heating Cable
